Type:All in one heat pump water heater
Circulation Type:Water to Water
Function:Domestic hot water supply
Installation:Vetical only
Compressor Type:DC Inverter
Refrigerant:R290/R134a
Certification:CE,ISO9001,SGS
Place of Origin:JIangsu, China
Brand Name:OEM
Storage:150L~500L included
Warranty:3 Years
| Main technical dates | |
| Capacity | 200L |
| Power supply | 220-240V/50Hz/1Phase |
| Max Current(under rapid mode) | 10.6A |
| Refrigerant | R290 |
| Compressor | HIGHLY |
| Fan Motor | DC Inverter |
| Fan Type | Axial |
| Expansion Valve | EEV |
| Defrost | Automatic |
| Rated Outlet Water Temperature | 60°C |
| Max Outlet Water Temperature | 75°C |
| Ambient working temperature | -10℃-43℃ |
| Ingress Protection Grade | IPX4 |
| Electric Shock Proof | Class I |
| Unpacked Dimension | φ580*1700mm |
| Packed Dimension | 650*650*1860mm |
| Optional Running at Eco Mode (Heat pump only) | |
| Heating Capacity | 1.95kW |
| Rated Input Power | 0.35kW |
| COP | 5.6 |
| Recharge Rate Per Hour | 37L/h |
| Heating Time from 15℃ to 55℃ (Air temperature 15℃) | 5.41hours |
| Noise Level | 49 dB (A) |
| Optional Running at Rapid Mode(Heat pump+Electric heater) | |
| Heating Capacity | 4.5kw |
| Rated Input Power | 2.46kw |
| Electric Heating Element | 2KW |
| COP | 5.43 |
| Recharge Rate Per Hour | 70L/h |
| Heating Time from 15℃ to 55℃ (Air temperature 15℃) | 2.85hours |
| Storage Tank Details | |
| Capacity | 200L |
| Inner Tank | Enameled 2.5mm thickness of steel plate or Stainless SteelSUS3042B |
| Insulation of Tank Polyurethane thickness | 50mm |
| Heat Exchanger | Microchannel |
| Outer Casing | Powder coating galvanized steel plate |
| TPR valve | AVG /850kPa |
| Others capacity 150L~500L please click here | |
